Volume pricing
- 1+ pcs$7.71
- 10+ pcs$7.27
- 100+ pcs$6.86
- 500+ pcs$6.47
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Ambalaj
- Tray
- Montaj
- Through Hole
- Terminal Stili
- PC Pin
- Fabrika Tedarik Süresi
- 10 Weeks
- Current Rating Amps
- 0.4VA AC/DC
- Terminal
- PC Pin
- Length Termination
- 0.122 inch
- Contact Style
- Non-Shorting
- Illumination Type
- Non-Illuminated
- Dielectric Withstanding Voltage
- 500VAC V
- Çalışma Sıcaklığı
- -30°C~85°C
- Montaj Tipi
- Through Hole, Right Angle
- Contact Finish
- Gold
- Orientation
- Right Angle
- Contact Resistance
- 0.05mOhm
- Seri
- AS
- Yayın Yılı
- 2006
- Contact Dc Max Power Rating R Load
- 0.4VA@28VDC
- Kurşunsuz Kodu
- yes
- Body Length Or Diameter
- 9.8044mm
- Switch Travel
- 2.50mm
- Voltage Rated Dc
- 28V
- Body Breadth
- 10.0076 mm
- RoHS Durumu
- ROHS3 Compliant
- Actuator Material
- Polyamide (PA), Nylon, Glass Filled
- Actuator Length
- 3.80mm
- Mechanical Life
- 50,000 Cycles
- Contact Timing
- Non-Shorting (BBM)
- Parça Durumu
- Active
- Insulation Resistance
- 500000000Ohm
- Body Height
- 12.4206mm
- Contact Materials
- Phosphor Bronze
- Voltage Rated Ac
- 28V
- Electricallife
- 50,000 Cycles
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Switch Function
- On-Off-On
- Actuator Type
- Standard
- Operating Force
- 260gf
- Özellikler
- Epoxy Sealed Terminals
- Circuit
- DPDT
