Volume pricing
- 1+ pcs$8.01
- 10+ pcs$7.56
- 100+ pcs$7.13
- 500+ pcs$6.73
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Fabrika Tedarik Süresi
- 9 Weeks
- Current Rating Amps
- 0.4VA AC/DC
- Terminal
- PC Pin
- Terminal Stili
- Wire Wrap
- Montaj
- Through Hole
- Ambalaj
- Tube
- Çalışma Sıcaklığı
- -30°C~85°C
- Montaj Tipi
- Through Hole
- Contact Finish
- Gold
- Orientation
- Vertical
- Yayın Yılı
- 2010
- Seri
- AS
- Min. Çalışma Sıcaklığı
- -30°C
- Maks. Çalışma Sıcaklığı
- 85°C
- Illumination Type
- Non-Illuminated
- RoHS Durumu
- ROHS3 Compliant
- Actuator Length
- 2.50mm
- Actuator Material
- Polyamide (PA), Nylon, Glass Filled
- Switch Travel
- 2.50mm
- Voltage Rated Dc
- 28V
- Electricallife
- 50,000 Cycles
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Switch Function
- On-Off-On
- Operating Force
- 260gf
- Actuator Type
- Standard
- Circuit
- DPDT
- Özellikler
- Epoxy Sealed Terminals
- Mechanical Life
- 50,000 Cycles
- Contact Plating
- Gold
- Contact Timing
- Non-Shorting (BBM)
- Parça Durumu
- Active
- Voltage Rated Ac
- 28V
- Throw Configuration
- DPDT
- Contact Materials
- Phosphor Bronze
