Volume pricing
- 1+ pcs$7.41
- 10+ pcs$6.99
- 100+ pcs$6.59
- 500+ pcs$6.22
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Terminal Stili
- PC Pin
- Pozisyon Sayısı
- 3
- Ambalaj
- Tray
- Montaj
- Through Hole
- Additional Feature
- MOUNTING BRACKET
- Max Current Rating
- 100mA
- Montaj Tipi
- Through Hole
- Contact Dc Max Power Rating R Load
- 0.4VA@28VDC
- Contact Resistance
- 0.05mOhm
- Switch Type
- SLIDE SWITCH
- Voltage Rated Dc
- 28V
- RoHS Durumu
- ROHS3 Compliant
- Actuator Material
- Polyamide (PA), Nylon, Glass Filled
- Actuator Length
- 2.50mm
- ECCN Kodu
- EAR99
- Voltage Rated Ac
- 28V
- Body Height
- 14.6812mm
- Pcb Hole Count
- 10
- Mechanical Life
- 50,000 Cycles
- Parça Durumu
- Active
- Insulation Resistance
- 500000000Ohm
- Operating Force
- 260gf
- Actuator Type
- Standard
- Circuit
- DPDT
- Özellikler
- Epoxy Sealed Terminals
- Switch Function
- On-Off-On
- JESD-609 Kodu
- e4
- Terminal
- PC Pin
- Max Voltage Rating Dc
- 28V
- Fabrika Tedarik Süresi
- 5 Weeks
- Current Rating Amps
- 0.4VA AC/DC
- Actuatorcolor
- WHITE
- Uzunluk
- 10.46mm
- Contact Style
- Non-Shorting
- Contact Finish
- Gold
- Yayın Yılı
- 2006
- Seri
- AS
- Max Voltage Rating Ac
- 28V
- Çalışma Sıcaklığı
- -30°C~85°C
- Solderability
- WAVE
