Specifications
- Contact Currentacmax
- 0.014A
- Max Voltage Rating Ac
- 28V
- Dielectric Withstanding Voltage
- 500VAC V
- Çalışma Sıcaklığı
- -30°C~85°C
- Solderability
- WAVE
- Contact Finish
- Gold
- Seri
- AS
- Uzunluk
- 9.8mm
- Actuatorcolor
- WHITE
- Contact Style
- Non-Shorting
- Illumination Type
- Non-Illuminated
- Fabrika Tedarik Süresi
- 11 Weeks
- HTS Kodu
- 8536.50.90.50
- Current Rating Amps
- 0.4VA AC/DC
- Terminal
- PC Pins
- Max Voltage Rating Dc
- 28V
- JESD-609 Kodu
- e4
- Electricallife
- 50,000 Cycles
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Kurşunsuz
- Lead Free
- Insulation Materials
- CARBON COMPOSITE POLYMER
- Contact Timing
- Non-Shorting (BBM)
- Contact Materials
- Phosphor Bronze
- Kurşunsuz Kodu
- yes
- Reach Svhc
- No SVHC
- Depth
- 9.2mm
- Contact Dc Max Rating R Load
- .014A@28VDC
- Montaj Tipi
- Through Hole
- Orientation
- Vertical
- Contact Resistance
- 0.05mOhm
- Contact Dc Max Power Rating R Load
- 0.4VA@28VDC
- Max Current Rating
- 100mA
- Sealing
- EPOXY TERMINAL SEALED
- Montaj
- PCB, Through Hole
- Ambalaj
- Tray
- Terminal Stili
- PC Pin
- Pozisyon Sayısı
- 3
- Switching Capacity
- 400 mW
- Contact Currentdcmax
- 0.014A
- Switching Voltage
- 28V
