Volume pricing
- 1+ pcs$6.58
- 10+ pcs$6.20
- 100+ pcs$5.85
- 500+ pcs$5.52
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Circuit
- DPDT
- Özellikler
- Epoxy Sealed Terminals
- Operating Force
- 260gf
- Actuator Type
- Standard
- Switch Function
- On-On
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Electricallife
- 50,000 Cycles
- Pcb Hole Count
- 10
- Voltage Rated Ac
- 28V
- Body Height
- 14.6812mm
- Contact Materials
- Phosphor Bronze
- Contact Timing
- Non-Shorting (BBM)
- Insulation Materials
- CARBON COMPOSITE POLYMER
- Parça Durumu
- Active
- Insulation Resistance
- 500000000Ohm
- Mechanical Life
- 50,000 Cycles
- Kurşunsuz
- Lead Free
- Actuator Material
- Polyamide (PA), Nylon, Glass Filled
- Actuator Length
- 2.50mm
- RoHS Durumu
- ROHS3 Compliant
- Body Breadth
- 9.4996 mm
- Voltage Rated Dc
- 28V
- Body Length Or Diameter
- 9.8044mm
- Switch Type
- SLIDE SWITCH
- Kurşunsuz Kodu
- yes
- Yayın Yılı
- 2006
- Contact Dc Max Power Rating R Load
- 0.4VA@28VDC
- Contact Resistance
- 0.05mOhm
- Seri
- AS
- Montaj Tipi
- Through Hole
- Contact Finish
- Gold
- Solderability
- WAVE
- Çalışma Sıcaklığı
- -30°C~85°C
- Contact Current Rating
- 100mA
- Dielectric Withstanding Voltage
- 500VAC V
- Additional Feature
- MOUNTING BRACKET
- Contact Style
- Non-Shorting
- Actuatorcolor
- WHITE
- Terminal
- PC Pin
- Length Termination
- 0.122 inch
