Specifications
- Circuit
- SPDT
- Montaj Tipi
- Through Hole
- Voltage Rated Dc
- 28V
- Contact Finish
- Gold
- Mechanical Life
- 50,000 Cycles
- Özellikler
- Epoxy Sealed Terminals
- Voltage Rated Ac
- 28V
- Switch Travel
- 2.50mm
- Terminal Stili
- Wire Wrap
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Actuator Type
- Standard
- Switch Function
- On-Off-On
- Contact Timing
- Non-Shorting (BBM)
- Illumination Type
- Non-Illuminated
- Ambalaj
- Tray
- Fabrika Tedarik Süresi
- 10 Weeks
- Çalışma Sıcaklığı
- -30°C~85°C
- Parça Durumu
- Active
- Montaj
- Through Hole
- Actuator Length
- 3.80mm
- Orientation
- Vertical
- Contact Plating
- Gold
- Seri
- AS
- RoHS Durumu
- ROHS3 Compliant
- Actuator Material
- Polyamide (PA), Nylon, Glass Filled
- Electricallife
- 50,000 Cycles
- Yayın Yılı
- 2010
- Maks. Çalışma Sıcaklığı
- 85°C
- Current Rating Amps
- 0.4VA AC/DC
- Min. Çalışma Sıcaklığı
- -30°C
- Throw Configuration
- SPDT
- Contact Materials
- Phosphor Bronze
- Terminal
- PC Pin
- Operating Force
- 260gf
