Volume pricing
- 1+ pcs$5.84
- 10+ pcs$5.51
- 100+ pcs$5.20
- 500+ pcs$4.90
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Contact Finish
- Gold
- Body Breadth
- 5.6896 mm
- Montaj Tipi
- Through Hole, Right Angle, Vertical
- Voltage Rated Dc
- 28V
- Switch Type
- SLIDE SWITCH
- Contact Style
- Non-Shorting
- Switch Function
- On-Off-On
- Mechanical Life
- 50,000 Cycles
- Voltage Rated Ac
- 28V
- Actuator Length
- 3.80mm
- Ambalaj
- Tray
- Fabrika Tedarik Süresi
- 10 Weeks
- Çalışma Sıcaklığı
- -30°C~85°C
- Insulation Resistance
- 500000000Ohm
- Kurşunsuz
- Lead Free
- Pozisyon Sayısı
- 3
- Current Rating Amps
- 0.4VA AC/DC
- Contact Materials
- Phosphor Bronze
- Actuatorcolor
- WHITE
- Seri
- AS
- Electricallife
- 50,000 Cycles
- Uzunluk
- 5.7mm
- Depth
- 19.1mm
- Body Height
- 19.0754mm
- Circuit
- SPDT
- Max Current Rating
- 100mA
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Actuator Type
- Standard
- Additional Feature
- MOUNTING BRACKET
- Switch Travel
- 2.50mm
- Terminal Stili
- PC Pin
- Contact Dc Max Power Rating R Load
- 0.4VA@28VDC
- Pcb Hole Count
- 5
- Contact Timing
- Non-Shorting (BBM)
- Illumination Type
- Non-Illuminated
- Özellikler
- Epoxy Sealed Terminals
- ECCN Kodu
- EAR99
- Solderability
- WAVE
- Max Voltage Rating Ac
- 28V
- Montaj
- Through Hole, Vertical
