Volume pricing
- 1+ pcs$4.77
- 10+ pcs$4.50
- 100+ pcs$4.25
- 500+ pcs$4.01
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Terminal Stili
- PC Pin
- Insulation Resistance
- 500000000Ohm
- Contact Dc Max Power Rating R Load
- 0.4VA@28VDC
- Pcb Hole Count
- 5
- Actuator Length
- 2.50mm
- Circuit
- SPST
- Seri
- AS
- Reach Svhc
- No SVHC
- Solderability
- WAVE
- Fabrika Tedarik Süresi
- 5 Weeks
- Actuator Type
- Standard
- Max Voltage Rating Ac
- 28V
- Montaj Tipi
- Through Hole, Right Angle, Vertical
- Contact Materials
- Phosphor Bronze
- Body Height
- 17.7546mm
- Operating Force
- 260gf
- Parça Durumu
- Active
- Orientation
- Vertical
- Additional Feature
- MOUNTING BRACKET
- Uzunluk
- 5.7mm
- Switch Function
- On-Off
- Terminal
- PC Pin
- Actuator Material
- Polyamide (PA), Nylon, Glass Filled
- Actuatorcolor
- WHITE
- Çalışma Sıcaklığı
- -30°C~85°C
- Ambalaj
- Tray
- Body Breadth
- 5.6896 mm
- Contact Finish
- Gold
- Electricallife
- 50,000 Cycles
- Kurşunsuz
- Contains Lead
- Mechanical Life
- 50,000 Cycles
- Contact Timing
- Non-Shorting (BBM)
- Dielectric Withstanding Voltage
- 500VAC V
- Contact Resistance
- 0.05mOhm
- ECCN Kodu
- EAR99
- Max Current Rating
- 100mA
- JESD-609 Kodu
- e4
- Switch Type
- SLIDE SWITCH
- RoHS Durumu
- ROHS3 Compliant
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
