Volume pricing
- 1+ pcs$3.96
- 10+ pcs$3.73
- 100+ pcs$3.52
- 500+ pcs$3.32
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Montaj Tipi
- Through Hole
- Max Voltage Rating Ac
- 28V
- Actuator Type
- Standard
- Fabrika Tedarik Süresi
- 13 Weeks
- Solderability
- WAVE
- Yayın Yılı
- 2015
- Parça Durumu
- Active
- Operating Force
- 260gf
- Body Height
- 14.6812mm
- Contact Materials
- Phosphor Bronze
- Pcb Hole Count
- 3
- Contact Dc Max Power Rating R Load
- 0.4VA@28VDC
- Insulation Resistance
- 500000000Ohm
- Terminal Stili
- PC Pin
- Seri
- AS
- Circuit
- SPST
- Actuator Length
- 2.50mm
- Illumination Type
- Non-Illuminated
- RoHS Durumu
- ROHS3 Compliant
- Switch Type
- SLIDE SWITCH
- Max Current Rating
- 100mA
- JESD-609 Kodu
- e4
- ECCN Kodu
- EAR99
- Insulation Materials
- CARBON COMPOSITE POLYMER
- Kurşunsuz Kodu
- yes
- Max Voltage Rating Dc
- 28V
- Voltage Rated Dc
- 28V
- Özellikler
- Epoxy Sealed Terminals
- Montaj
- Through Hole
- Contact Style
- Non-Shorting
- Voltage Rated Ac
- 28V
- Depth
- 5.38mm
- Current Rating Amps
- 0.4VA AC/DC
- Pozisyon Sayısı
- 3
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Electricallife
- 50,000 Cycles
- Contact Finish
- Gold
- Body Breadth
- 5.3848 mm
- Ambalaj
- Tray
- Çalışma Sıcaklığı
- -30°C~85°C
