Volume pricing
- 1+ pcs$4.56
- 10+ pcs$4.30
- 100+ pcs$4.06
- 500+ pcs$3.83
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Circuit
- SPST
- Seri
- AS
- Actuator Length
- 2.50mm
- Contact Dc Max Power Rating R Load
- 0.4VA@28VDC
- Pcb Hole Count
- 5
- Terminal Stili
- PC Pin
- Insulation Resistance
- 500000000Ohm
- Parça Durumu
- Active
- Operating Force
- 260gf
- Orientation
- Right Angle
- Additional Feature
- MOUNTING BRACKET
- Yayın Yılı
- 2010
- Contact Materials
- Phosphor Bronze
- Body Height
- 12.6746mm
- Actuator Type
- Standard
- Montaj Tipi
- Through Hole, Right Angle
- Max Voltage Rating Ac
- 28V
- Reach Svhc
- No SVHC
- Solderability
- WAVE
- Fabrika Tedarik Süresi
- 9 Weeks
- Contact Timing
- Non-Shorting (BBM)
- Dielectric Withstanding Voltage
- 500VAC V
- Contact Resistance
- 0.05mOhm
- Kurşunsuz
- Lead Free
- Mechanical Life
- 50,000 Cycles
- Actuatorcolor
- WHITE
- Çalışma Sıcaklığı
- -30°C~85°C
- Ambalaj
- Tray
- Contact Finish
- Gold
- Electricallife
- 50,000 Cycles
- Body Breadth
- 6.1722 mm
- Switch Function
- On-Off
- Uzunluk
- 9.8mm
- Terminal
- PC Pins
- Actuator Material
- Polyamide (PA), Nylon, Glass Filled
- Voltage Rated Dc
- 28V
- Max Voltage Rating Dc
- 28V
- Kurşunsuz Kodu
- yes
- Özellikler
- Epoxy Sealed Terminals
- Montaj
- PCB, Through Hole
