Volume pricing
- 1+ pcs$5.90
- 10+ pcs$5.57
- 100+ pcs$5.25
- 500+ pcs$4.95
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- ECCN Kodu
- EAR99
- Solderability
- WAVE
- Fabrika Tedarik Süresi
- 9 Weeks
- JESD-609 Kodu
- e4
- Max Current Rating
- 100mA
- RoHS Durumu
- Non-RoHS Compliant
- Actuator Type
- Plunger for Cap
- Max Voltage Rating Ac
- 28V
- Montaj Tipi
- Through Hole, Right Angle, Vertical
- Housing Material
- GLASS FILLED POLYAMIDE
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Current Rating Amps
- 0.4VA AC/DC
- Contact Materials
- Brass
- Contact Plating
- Gold
- Color Actuatorcap
- White
- Body Height
- 14.4526mm
- Voltage Rated Ac
- 28V
- Özellikler
- Sealed - Fully
- Montaj
- PCB, Through Hole, Vertical
- Voltage Rated Dc
- 28V
- Max Voltage Rating Dc
- 28V
- Tip
- Standard
- Parça Durumu
- Active
- Kurşunsuz Kodu
- yes
- Yayın Yılı
- 2015
- Orientation
- Vertical
- Switch Function
- On-Mom
- Terminal Stili
- PC Pin
- Terminal
- PC Pin
- Uzunluk
- 5.84mm
- Sealing
- EPOXY
- Actuator Material
- Polyacetal
- Insulation Resistance
- 500000000Ohm
- Çalışma Sıcaklığı
- -30°C~85°C
- Ambalaj
- Tray
- Contact Dc Max Power Rating R Load
- 0.4VA@28VDC
- Body Breadth
- 10.2108 mm
- Electricallife
- 50,000 Cycles
- Kurşunsuz
- Lead Free
- Mechanical Life
- 50,000 Cycles
