Volume pricing
- 1+ pcs$4.66
- 10+ pcs$4.39
- 100+ pcs$4.15
- 500+ pcs$3.91
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Current Rating Amps
- 0.4VA AC/DC
- Voltage Rated Dc
- 28V
- Çalışma Sıcaklığı
- -30°C~85°C
- Seri
- AB
- Montaj Tipi
- Through Hole, Right Angle, Vertical
- Color Actuatorcap
- Red
- Washability
- SOLVENT
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Orientation
- Vertical
- Throw Configuration
- SPST
- Yayın Yılı
- 2010
- Montaj
- Through Hole, Vertical
- Kurşunsuz
- Contains Lead
- Actuator Length
- 0.248 inch
- Actuator Travel
- 1.0922 mm
- Contact Plating
- Gold
- Insulation Resistance
- 500000000Ohm
- JESD-609 Kodu
- e4
- Body Length Or Diameter
- 10.2108mm
- Terminal
- PC Pin
- Pcb Hole Count
- 5
- Parça Durumu
- Active
- Tip
- Standard
- Circuit
- SPST-NO
- Body Breadth
- 5.842 mm
- Solderability
- WAVE
- Electricallife
- 50,000 Cycles
- RoHS Durumu
- ROHS3 Compliant
- Fabrika Tedarik Süresi
- 5 Weeks
- Center Contact Material
- PHOSPHOR BRONZE
- Life Cycles
- 50000 cycles
- Ambalaj
- Tray
- Actuator Material
- POLYCARBONATE
- Contact Resistance
- 0.05mOhm
- End Contact Material
- BRASS
- Power Rating
- 400mW
- Dielectric Withstanding Voltage
- 500VAC V
- Switch Function
- Off-Mom
- Housing Material
- Polyamide
- Mechanical Life
- 50,000 Cycles
