Volume pricing
- 1+ pcs$6.17
- 10+ pcs$5.82
- 100+ pcs$5.49
- 500+ pcs$5.18
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Özellikler
- Sealed - Fully
- Sealing
- EPOXY
- Voltage Rated Ac
- 28V
- Contact Materials
- Bronze
- Max Voltage Rating Ac
- 28V
- Kurşunsuz Kodu
- yes
- Housing Material
- Polyamide
- Terminal Stili
- PC Pin
- Mechanical Life
- 50,000 Cycles
- Actuator Type
- Round, Button
- Contact Function
- OFF-(ON)
- Body Height
- 21.7424mm
- Actuator Material
- Polyacetal
- Contact Resistance
- 0.05mOhm
- Ambalaj
- Tray
- Dielectric Withstanding Voltage
- 500VAC V
- Switch Function
- Off-Mom
- Power Rating
- 400mW
- Fabrika Tedarik Süresi
- 5 Weeks
- Electricallife
- 50,000 Cycles
- RoHS Durumu
- ROHS3 Compliant
- Max Voltage Rating Dc
- 28V
- Parça Durumu
- Active
- Pcb Hole Count
- 2
- Body Breadth
- 5.842 mm
- Solderability
- WAVE
- Circuit
- SPST-NO
- Tip
- Standard
- JESD-609 Kodu
- e4
- Contact Plating
- Gold
- Insulation Resistance
- 500000000Ohm
- ECCN Kodu
- EAR99
- Terminal
- PC Pin
- Yayın Yılı
- 2015
- Kurşunsuz
- Lead Free
- Uzunluk
- 9.8mm
- Montaj
- Through Hole
- Max Current Rating
- 100mA
- Current Rating Amps
- 0.4VA AC/DC
- Voltage Rated Dc
- 28V
