Volume pricing
- 1+ pcs$7.24
- 10+ pcs$6.83
- 100+ pcs$6.44
- 500+ pcs$6.08
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Fabrika Tedarik Süresi
- 5 Weeks
- Electricallife
- 50,000 Cycles
- RoHS Durumu
- ROHS3 Compliant
- Center Contact Material
- PHOSPHOR BRONZE
- End Contact Material
- BRASS
- Actuator Material
- POLYCARBONATE
- Contact Resistance
- 0.05mOhm
- Life Cycles
- 50000 cycles
- Ambalaj
- Tray
- Dielectric Withstanding Voltage
- 500VAC V
- Switch Function
- Off-Mom
- Power Rating
- 400mW
- Kurşunsuz Kodu
- yes
- Housing Material
- Polyamide
- Terminal Stili
- PC Pin
- Mechanical Life
- 50,000 Cycles
- Actuator Type
- Round, Button
- Contact Function
- OFF-(ON)
- Body Height
- 21.7424mm
- Özellikler
- Sealed - Fully
- Sealing
- EPOXY
- Additional Feature
- MOUNTING BRACKET
- Voltage Rated Ac
- 28V
- Length Termination
- 0.122 inch
- Bushing Length
- 0.177 inch
- Current Rating Amps
- 0.4VA AC/DC
- Voltage Rated Dc
- 28V
- Orientation
- Vertical
- Throw Configuration
- SPST
- Seri
- AB
- Montaj Tipi
- Through Hole
- Color Actuatorcap
- Black
- Çalışma Sıcaklığı
- -30°C~85°C
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Washability
- SOLVENT
- Yayın Yılı
- 2010
- Kurşunsuz
- Contains Lead
- Actuator Length
- 0.248 inch
- Montaj
- Through Hole
- JESD-609 Kodu
- e4
