NJM4560D

Specifications

Number Of Channels

2

Number Of Circuits

2

Min. Çalışma Sıcaklığı

-40 °C

Montaj

Through Hole

Power Dissipation

500 mW

Nominal Supply Current

5.7 mA

Voltage Gain

100 dB

Common Mode Rejection Ratio

70 dB

Casepackage

DIP

Radyasyon Dayanımı

No

Min Dual Supply Voltage

4 V

Max Supply Voltage

18 V

Slew Rate

4 V/µs

Number Of Elements

2

Max Dual Supply Voltage

18 V

Input Bias Current

40 nA

Gain Bandwidth Product

10 MHz

Kurşunsuz

Contains Lead, Lead Free

RoHS

Compliant

Maks. Çalışma Sıcaklığı

85 °C

Pin Sayısı

8

Operating Supply Current

4.3 mA

Input Offset Voltage Vos

6 mV
