NJM4559D

Specifications

Casepackage

DIP

Voltage Gain

100 dB

Common Mode Rejection Ratio

70 dB

Montaj

Through Hole

Power Dissipation

500 mW

Nominal Supply Current

5.7 mA

Min. Çalışma Sıcaklığı

-40 °C

Number Of Channels

2

Number Of Circuits

2

Pin Sayısı

8

Maks. Çalışma Sıcaklığı

85 °C

Operating Supply Current

3.5 mA

Input Offset Voltage Vos

6 mV

Kurşunsuz

Lead Free

RoHS

Compliant

Input Bias Current

25 nA

Gain Bandwidth Product

6 MHz

Radyasyon Dayanımı

No

Max Dual Supply Voltage

18 V

Number Of Elements

2

Min Dual Supply Voltage

4 V

Max Supply Voltage

18 V

Slew Rate

2 V/µs
