NJM319M

Specifications

Nem Hassasiyeti (MSL)

2 (1 Year)

Max Dual Supply Voltage

18 V

Number Of Channels

2

Input Bias Current

1 µA

Çıkış Tipi

TTL

Number Of Elements

2

Number Of Circuits

2

Output Current

25 mA

Voltage Gain

92 dB

Current Output Typ

25mA

Voltage Input Offset Max

8mV @ ±15V

Tedarikçi Cihaz Paketi

14-DMP

RoHS Durumu

RoHS Compliant

RoHS

Compliant

Min Supply Voltage

5 V

Voltage Supply Singledual

5V~36V ±2.5V~18V

Casepackage

SOIC

Montaj

Surface Mount

Output Current Per Channel

25 mA

Yayın Yılı

2003

Çalışma Sıcaklığı

-40°C~85°C

Max Supply Voltage

36 V

Nominal Supply Current

12.5 mA

Kurşunsuz

Lead Free

Parça Durumu

Obsolete

Montaj Tipi

Surface Mount

Quiescent Current

12.5 mA

Kılıf / Paket

14-SOIC (0.209, 5.30mm Width)

Current Input Bias Max

1μA @ ±15V

Input Offset Voltage Vos

8 mV

Max Power Dissipation

300 mW

Ambalaj

Tube

Response Time

8 ns

Max Supply Current

12.5 mA

Maks. Çalışma Sıcaklığı

85 °C

Min Dual Supply Voltage

5 V

Pin Sayısı

14

Tip

General Purpose

Max Input Current

1 µA

Fabrika Tedarik Süresi

12 Weeks
