NJM2114M

Specifications

Min Dual Supply Voltage

3 V

Common Mode Rejection Ratio

70 dB

Montaj

Surface Mount

Nominal Supply Current

16 mA

Gain Bandwidth Product

13 MHz

Min. Çalışma Sıcaklığı

-20 °C

Maks. Çalışma Sıcaklığı

75 °C

Max Dual Supply Voltage

22 V

Radyasyon Dayanımı

No

Power Dissipation

600 mW

Input Bias Current

1.8 µA

Pin Sayısı

8

Slew Rate

15 V/µs

Number Of Channels

2

RoHS

Compliant

Operating Supply Voltage

22 V

Voltage Gain

110 dB

Input Offset Voltage Vos

3 mV

Number Of Elements

2
