NJM2043D

Specifications

Min. Çalışma Sıcaklığı

-20 °C

Nominal Supply Current

8 mA

Montaj

Through Hole

Maks. Çalışma Sıcaklığı

75 °C

Operating Supply Voltage

22 V

Max Dual Supply Voltage

22 V

Slew Rate

6 V/µs

Power Dissipation

500 mW

Min Dual Supply Voltage

4 V

Casepackage

DIP

Voltage Gain

100 dB

Kurşunsuz

Lead Free

RoHS

Compliant

Number Of Elements

2

Radyasyon Dayanımı

No

Input Offset Voltage Vos

3 mV

Common Mode Rejection Ratio

70 dB

Pin Sayısı

8

Input Bias Current

1 µA

Gain Bandwidth Product

14 MHz

Number Of Channels

2
