NHD-2.23-12832UMY3

Specifications

Pin Sayısı

24

Operating Supply Voltage

3V

Background Color

Black

Graphics Color

Yellow

Resolution Width

128 pixel

Contrast Ratio

2000:1

Brightness

120 cd/m^2

Dot Pixels

128 x 32

Diagonal Size

2.23 in

Resolution Height

32 pixel

Diagonal Screen Size

2.23 56.64mm

Nem Hassasiyeti (MSL)

Not Applicable

Illumination Color

Yellow

RoHS Durumu

RoHS Compliant

Min. Çalışma Sıcaklığı

-20°C

Touchscreen

No

Controller Type

SSD1305

Parça Durumu

Active

Backlight

Without Backlight

Viewing Area

60.00mm W x 18.00mm H

Viewing Angle

80 °

Maks. Çalışma Sıcaklığı

70°C

Montaj

Screw

Kılıf / Paket

Module

Operating Supply Current

75mA

Interface

I2C, Parallel 8-Bit, SPI

Display Type

OLED - Passive Matrix
