NHD-0212WH-ATGH-JT#

Specifications

Besleme Gerilimi

5V

Overall Depth

14.5mm

Text Color

Blue

Dot Size

0.45mm Wx0.60mm H

Yayın Yılı

2013

Number Of Characters

24

Rows Per Display

2

Nem Hassasiyeti (MSL)

Not Applicable

Overall Height

32mm

Parça Durumu

Active

Characters Per Row

12

Character Font Type

5x8 Dot

Backlight

LED - White

Overall Length

55.7mm

Display Format

12 x 2

Çalışma Sıcaklığı

-20°C~70°C

Controller Type

ST7066

Backlight Type

LED

Display Mode

Transflective

Character Size

5.50mm Hx2.65mm W

RoHS Durumu

RoHS Compliant

Fabrika Tedarik Süresi

14 Weeks

Operating Supply Voltage

5V

Viewing Area

46.00mm L x 14.50mm W

Ambalaj

Bulk

Display Type

STN - Super-Twisted Nematic

Outline LXWXH

55.70mm x 32.00mm x 14.50mm

Character Format

5 x 8 Dots

Besleme Gerilimi

4.5V~5.5V

Background Color

White

Interface

Parallel

Display Height

5.5mm
