NHD-0116GZ-NSW-BBW

Specifications

RoHS Durumu

RoHS Compliant

Contrast Ratio

2:1

Character Size

14.54mm Hx6.00mm W

Display Mode

Transmissive

Backlight Type

LED

Controller Type

SPLC780D OR ST7066U

Besleme Gerilimi

4.7V~5.5V

Background Color

Blue

Character Format

5 x 8 Dots

Montaj

Screw

Display Height

14.54mm

Interface

Parallel

Kılıf / Paket

Module

Operating Supply Voltage

5V

Fabrika Tedarik Süresi

14 Weeks

Viewing Area

120.00mm L x 23.00mm W

Display Type

STN - Super-Twisted Nematic

Outline LXWXH

151.00mm x 40.00mm x 13.00mm

Nem Hassasiyeti (MSL)

Not Applicable

Rows Per Display

1

Overall Height

40mm

Parça Durumu

Active

Besleme Gerilimi

5V

Dot Size

1.15mm Wx1.77mm H

Yayın Yılı

2011

Number Of Characters

16

Overall Depth

13mm

Text Color

White

Backlight

LED - White

Çalışma Sıcaklığı

-20°C~70°C

Display Format

16 x 1

Overall Length

151mm

Characters Per Row

16

Character Font Type

5x7 + CSR
