Specifications
- Pin Sayısı
- 24
- Max Power Dissipation
- 2W
- Maks. Oturma Yüksekliği
- 7.6mm
- Propagation Delay
- 72 ns
- Isolated Power
- No
- Data Rate
- 1.25Mbps
- Terminal Pozisyonu
- DUAL
- Terminal Kaplaması
- MATTE TIN OVER NICKEL
- Montaj Tipi
- Through Hole
- Montaj
- Through Hole
- Kurşunsuz Kodu
- yes
- Receiver Number Of Bits
- 2
- Logic Function
- Receiver, Transceiver
- Channel Type
- Unidirectional
- Reach Svhc
- No SVHC
- Number Of Transceivers
- 1
- Number Of Channels
- 4
- Nominal Supply Current
- 20μA
- ECCN Kodu
- EAR99
- Number Of Drivers
- 2
- Interface
- RS-485
- Differential Output
- YES
- Besleme Gerilimi
- 4.75V~5.25V
- Besleme Gerilimi
- 5V
- Pin Sayısı
- 24
- Parça Durumu
- Obsolete
- Fonksiyon Sayısı
- 2
- Power Supplies
- 5V
- Çalışma Sıcaklığı
- 0°C~60°C
- Tip
- General Purpose
- Ambalaj
- Tube
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Operating Supply Voltage
- 5V
- Terminal Sayısı
- 24
- Voltage Isolation
- 1000Vrms
- JESD-609 Kodu
- e3
- Inputs Side1side2
- 2/2
- Kılıf / Paket
- 24-DIP (0.667, 16.95mm)
- RoHS Durumu
- RoHS Compliant
- Input Characteristics
- DIFFERENTIAL SCHMITT TRIGGER
