Specifications
- Contact Materials
- PHOSPHOR BRONZE
- Reliability
- COMMERCIAL
- Kurşunsuz Kodu
- icon-pbfree yes
- Mating Contact Pitch
- 0.098 inch
- Number Of Pcb Rows
- 1
- Total Number Of Contacts
- 7
- Parça Durumu
- Discontinued
- Connector Type
- PCB CONNECTOR
- Terminal Adımı
- 2.4892mm
- Contact Resistance
- 50mOhm
- Operating Temperature Min
- -25°C
- Contact Finish Termination
- Tin (Sn)
- REACH Uyumluluk Kodu
- compliant
- Rated Current Signal
- 0.5A
- Termination Type
- SURFACE MOUNT
- Body Breadth
- 0.094 inch
- Sıra Sayısı
- 1
- Iec Conformance
- NO
- Number Of Conductors
- ONE
- RoHS Durumu
- RoHS Compliant
- Yayın Yılı
- 2005
- Mil Conformance
- NO
- Plating Thickness
- 30u inch
- Montaj Tipi
- BOARD
- Body Length Or Diameter
- 1.047 inch
- Insulation Resistance
- 1000000000Ohm
- Reference Standard
- UL
- Number Of Ports
- 1
- Din Conformance
- NO
- JESD-609 Kodu
- e3
- Contact Gender
- MALE
- Body Depth
- 0.906 inch
- Insulator Color
- BLACK
- Insulation Materials
- LIQUID CRYSTAL POLYMER (LCP)
- Operating Temperature Max
- 90°C
- Contact Pattern
- RECTANGULAR
- Board Mounting Option
- SOLDER HOLDING POSTS
- Pcb Contact Pattern
- RECTANGULAR
- Montaj Stili
- RIGHT ANGLE
- Contact Finish Mating
- GOLD (30)
