Specifications
- Connector Type
- Male Pin, Plug
- Bodyshell Style
- RECEPTACLE
- Fabrika Tedarik Süresi
- 5 Weeks
- Filter Feature
- NO
- Option
- GENERAL PURPOSE
- Glow Wire Compliant
- Non-compliant
- Sıra Sayısı
- 1
- Number Of Contacts
- 3
- Terminal
- Crimp
- Contact Pattern
- RECTANGULAR
- Onay Kuruluşu
- CSA, UL
- Montaj
- Panel
- Mixed Contacts
- NO
- Din Conformance
- NO
- Housing Material
- Polyester
- Yayın Yılı
- 2008
- Orientation
- Straight
- Contact Style
- SQ PIN-SKT
- Radyasyon Dayanımı
- No
- Polarization Key
- POLARIZED HOUSING
- Uzunluk
- 19.05mm
- Maks. Çalışma Sıcaklığı
- 120°C
- Mil Conformance
- NO
- Renk
- Black
- Min. Çalışma Sıcaklığı
- -40°C
- Rated Current Signal
- 3A
- Iec Conformance
- NO
- RoHS Durumu
- RoHS Compliant
- Reach Svhc
- No SVHC
- Contact Gender
- Male
- Flammability Rating
- UL94 V-0
- Kurşunsuz Kodu
- yes
- Depth
- 24.26mm
- Pitch
- 2.54mm
- Reference Standard
- UL, CSA
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Wire Size Max
- 22 AWG
- Ul Flammability Code
- 94V-0
- Parça Durumu
- Active
- Reliability
- COMMERCIAL
