Specifications
- Insulation Color
- Natural
- Contact Materials
- Copper Alloy
- Pitch Mating
- 0.079 2.00mm
- Operating Temperature Min
- -40°C
- Dielectric Withstanding Voltage
- 700VAC V
- Total Number Of Contacts
- 8
- Yayın Yılı
- 2015
- Durability
- 30 Cycles
- Mounting Option1
- LOCKING
- Contact Shape
- Square
- Insulation Height
- 0.236 6.00mm
- Parça Durumu
- Active
- Number Of Pcb Rows
- 1
- JESD-609 Kodu
- e3
- Style
- Board to Cable/Wire
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Ambalaj
- Tape & Reel (TR)
- Özellikler
- Solder Retention
- Reliability
- COMMERCIAL
- Contact Finish Mating
- Gold
- Number Of Conductors
- ONE
- Seri
- DuraClik 560020
- Sıra Sayısı
- 1
- Applications
- Automotive, Industrial
- Rated Current Signal
- 3A
- Contact Type
- Male Pin
- Stack Height Mating
- 9.3mm
- Pcb Contact Pattern
- RECTANGULAR
- Body Breadth
- 0.307 inch
- Montaj Tipi
- Surface Mount
- Terminal Adımı
- 2.0066mm
- Board Mounting Option
- FITTING NAIL
- Material Flammability Rating
- UL94 V-0
- Shrouding
- Shrouded - 4 Wall
- Fastening Type
- Latch Lock
- RoHS Durumu
- ROHS3 Compliant
- Polarization Key
- POLARIZED HOUSING
- Pozisyon Sayısı
- 8
- Terminal
- Solder
- Fabrika Tedarik Süresi
- 11 Weeks
