5600200620

Specifications

JESD-609 Kodu

e3

Nominal Gerilim

125V

Style

Board to Cable/Wire

Glow Wire Compliant

Non-compliant

Nem Hassasiyeti (MSL)

1 (Unlimited)

Reliability

COMMERCIAL

Insulation Height

0.315 8.00mm

Yükseklik

8.2mm

Durability

30 Cycles

Contact Materials

Copper Alloy

Reach Svhc

Unknown

Akım Değeri

3A

Dielectric Withstanding Voltage

700VAC V

Orientation

Vertical

Maks. Çalışma Sıcaklığı

125°C

Connector Type

Header

Fabrika Tedarik Süresi

11 Weeks

Mating Contact Pitch

0.079 inch

Number Of Positions Loaded

All

Min. Çalışma Sıcaklığı

-40°C

Shrouding

Shrouded - 4 Wall

RoHS Durumu

ROHS3 Compliant

Polarization Key

POLARIZED HOUSING

Contact Type

Male Pin

Stack Height Mating

9.3mm

Seri

DuraClik 560020

Sıra Sayısı

1

Applications

Automotive, Industrial

Ambalaj

Tape & Reel (TR)

Özellikler

Solder Retention

Contact Finish Mating

Tin

Contact Shape

Square

ECCN Kodu

EAR99

Number Of Contacts

6

Number Of Pcb Rows

1

Parça Durumu

Active

Yayın Yılı

2015

Body Length Or Diameter

0.732 inch

Insulation Color

Natural

Pitch Mating

0.079 2.00mm
