Specifications
- Lead Pitch
- 500μm
- Glow Wire Compliant
- Non-compliant
- JESD-609 Kodu
- e4
- Contact Plating
- Gold
- Contact Style
- CENTRONIC
- Contact Resistance
- 40mOhm
- RoHS Durumu
- RoHS Compliant
- Orientation
- Vertical
- Rated Current Signal
- 0.5A
- Sıra Sayısı
- 2
- Contact Pattern
- RECTANGULAR
- Housing Color
- Black
- Number Of Contacts
- 22
- Reach Svhc
- No SVHC
- Flammability Rating
- UL94 V-0
- Yayın Yılı
- 2010
- Halogen Free
- Low Halogen
- Fabrika Tedarik Süresi
- 20 Weeks
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Parça Durumu
- Active
- Polarization Key
- POLARIZED HOUSING
- Durability
- 30 Cycles
- Stack Height
- 1.5mm
- Body Depth
- 0.045 inch
- Gender
- Male
- Pitch
- 500μm
- Voltage Rated Dc
- 50V
- Plating Thickness
- 10μin
- Body Breadth
- 0.111 inch
- Number Of Conductors
- ONE
- Connector Type
- Plug
- Operating Temperature Max
- 105°C
- Operating Temperature Min
- -40°C
- Additional Feature
- Embossed Tape on Reel
- Contact Finish Mating
- NOT SPECIFIED
- Insulation Resistance
- 100000000Ohm
- Dielectric Withstanding Voltage
- 500VAC V
- Reliability
- COMMERCIAL
- Kurşunsuz
- Lead Free
- Terminal
- SMD/SMT
