Specifications
- Ambalaj
- Cut Tape (CT)
- Parça Durumu
- Active
- HTS Kodu
- 8536.69.40.40
- Durability
- 30 Cycles
- Shrouding
- Shrouded - 4 Wall
- Contact Type
- Male Pin
- Polarization Key
- POLARIZED HOUSING
- Body Depth
- 0.276 inch
- Contact Resistance
- 20mOhm
- Number Of Contacts
- 12
- Iec Conformance
- NO
- Yayın Yılı
- 2011
- Nominal Gerilim
- 125V
- Montaj Tipi
- Surface Mount
- JESD-609 Kodu
- e3
- Fastening Type
- Detent Lock
- Mil Conformance
- NO
- Contact Gender
- Male
- Kurşunsuz Kodu
- yes
- Montaj
- Surface Mount
- Pitch Mating
- 0.079 2.00mm
- Reliability
- COMMERCIAL
- Style
- Board to Board or Cable
- Orientation
- Vertical
- Contact Materials
- Brass
- Mating Contact Pitch
- 0.079 inch
- Dielectric Withstanding Voltage
- 500VDC V
- Option
- GENERAL PURPOSE
- Mixed Contacts
- NO
- Akım Değeri
- 1.5A
- Number Of Conductors
- ONE
- Max Voltage Rating Ac
- 125V
- Connector Type
- Header
- Insulation Height
- 0.276 7.00mm
- Özellikler
- Solder Retention
- Housing Material
- Thermoplastic
- Contact Shape
- Square
- Ul Flammability Code
- 94V-0
- Seri
- Mi II 55460
- Insulation Color
- Natural
