Specifications
- Seri
- Micro-Lock PLUS 505568
- Insulation Materials
- Polyamide (PA), Nylon, Glass Filled
- ECCN Kodu
- EAR99
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Number Of Positions Loaded
- All
- Applications
- Automotive, General Purpose, Industrial
- Contact Type
- Male Pin
- Insulation Color
- Black
- Style
- Board to Cable/Wire
- Connector Type
- Header
- Ambalaj
- Tape & Reel (TR)
- HTS Kodu
- 8536.69.40.30
- Sıra Sayısı
- 1
- Fabrika Tedarik Süresi
- 16 Weeks
- Terminal
- Solder
- Insulation Height
- 0.165 4.20mm
- Nominal Gerilim
- 50VAC/DC
- Contact Materials
- Brass
- Montaj Tipi
- Surface Mount
- Shrouding
- Shrouded - 4 Wall
- RoHS Durumu
- ROHS3 Compliant
- Fastening Type
- Push-Pull
- Parça Durumu
- Active
- Çalışma Sıcaklığı
- -40°C~105°C
- Material Flammability Rating
- UL94 V-0
- Contact Finish Thickness Post
- 39.4μin 1.00μm
- Pozisyon Sayısı
- 7
- Yayın Yılı
- 2016
- Current Rating Amps
- Varies by WireGAuge
- Stack Height Mating
- 7.4mm
- Contact Finish Thickness Mating
- 39.4μin 1.00μm
- Özellikler
- Solder Retention
- Pitch Mating
- 0.049 1.25mm
- Contact Finish Mating
- Tin
- Contact Shape
- Square
