Specifications
- Montaj Tipi
- Surface Mount
- Body Breadth
- 0.079 inch
- Insulation Materials
- LIQUID CRYSTAL POLYMER (LCP)
- Connector Type
- Receptacle, Center Strip Contacts
- Contact Gender
- FEMALE
- Operating Temperature Max
- 85°C
- Parça Durumu
- Obsolete
- Contact Pattern
- RECTANGULAR
- Özellikler
- Solder Retention
- Pitch
- 0.014 0.35mm
- Insulator Color
- BLACK
- Ambalaj
- Tape & Reel (TR)
- Pozisyon Sayısı
- 34
- Contact Finish
- Gold
- Reliability
- COMMERCIAL
- Height Above Board
- 0.024 0.61mm
- Dielectric Withstanding Voltage
- 350VAC V
- Seri
- SlimStack 504618
- Sıra Sayısı
- 2
- Contact Resistance
- 80mOhm
- Insulation Resistance
- 100000000Ohm
- Kurşunsuz Kodu
- yes
- Number Of Conductors
- ONE
- Body Length Or Diameter
- 0.319 inch
- Operating Temperature Min
- -40°C
- Durability
- 30 Cycles
- Contact Materials
- COPPER ALLOY
- RoHS Durumu
- ROHS3 Compliant
- Stack Height Mating
- 0.6mm
- JESD-609 Kodu
- e4
- Rated Current Signal
- 0.3A
- Fabrika Tedarik Süresi
- 8 Weeks
- Yayın Yılı
- 2015
- Reference Standard
- UL
- Pcb Contact Pattern
- RECTANGULAR
- Polarization Key
- POLARIZED HOUSING
- Number Of Pcb Rows
- 2
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Mounting Option1
- LOCKING
- Board Mounting Option
- FITTING NAIL
