Specifications
- Pcb Contact Pattern
- RECTANGULAR
- Body Breadth
- 0.065 inch
- Fabrika Tedarik Süresi
- 12 Weeks
- Iec Conformance
- NO
- Number Of Pcb Rows
- 2
- Contact Finish
- Gold
- Özellikler
- Solder Retention
- Contact Materials
- NOT SPECIFIED
- RoHS Durumu
- ROHS3 Compliant
- Rated Current Signal
- 0.3A
- Yayın Yılı
- 2012
- Parça Durumu
- Obsolete
- Mounting Option1
- LOCKING
- Mil Conformance
- NO
- Contact Resistance
- 80mOhm
- Body Length Or Diameter
- 0.137 inch
- Reliability
- COMMERCIAL
- Contact Gender
- MALE
- Pitch
- 0.016 0.40mm
- Insulation Materials
- LIQUID CRYSTAL POLYMER (LCP)
- Durability
- 30 Cycles
- Mixed Contacts
- NO
- Reference Standard
- UL
- Operating Temperature Min
- -40°C
- Contact Style
- BELLOWED TYPE
- Option
- GENERAL PURPOSE
- Connector Type
- Plug, Center Strip Contacts
- Seri
- SlimStack 503776
- Number Of Conductors
- ONE
- Contact Pattern
- RECTANGULAR
- Polarization Key
- POLARIZED HOUSING
- Din Conformance
- NO
- Height Above Board
- 0.027 0.68mm
- Stack Height Mating
- 0.8mm
- Filter Feature
- NO
- Operating Temperature Max
- 85°C
- Ambalaj
- Tape & Reel (TR)
- Sıra Sayısı
- 2
- Total Number Of Contacts
- 10
- Insulator Color
- BLACK
