Volume pricing
- 1+ pcs$0.15
- 10+ pcs$0.14
- 100+ pcs$0.14
- 500+ pcs$0.13
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- ECCN Kodu
- EAR99
- Contact Finish Mating
- NOT SPECIFIED
- Montaj Tipi
- Free Hanging (In-Line)
- Pozisyon Sayısı
- 4
- Fastening Type
- Friction Lock
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Operating Temperature Max
- 85°C
- Ambalaj
- Bulk
- Sıra Sayısı
- 1
- Note
- Contacts Not Included
- Filter Feature
- NO
- Total Number Of Contacts
- 4
- Additional Feature
- POLARIZED; PICO-LOCK
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Din Conformance
- NO
- Polarization Key
- POLARIZED HOUSING
- Connector Type
- Receptacle
- Seri
- Pico-Lock 503764
- Contact Termination
- Crimp
- Mixed Contacts
- NO
- Insulation Materials
- THERMOPLASTIC
- Pitch
- 0.039 1.00mm
- Insulation Diametermin
- 0.02 inch
- Option
- GENERAL PURPOSE
- Contact Type
- Female Socket
- Reference Standard
- UL
- Operating Temperature Min
- -25°C
- Parça Durumu
- Active
- Yayın Yılı
- 2013
- Mil Conformance
- NO
- Mounting Option1
- LOCKING
- RoHS Durumu
- ROHS3 Compliant
- Contact Materials
- NOT SPECIFIED
- Renk
- Black
- Body Length Or Diameter
- 0.339 inch
- Reliability
- COMMERCIAL
- Contact Resistance
- 20mOhm
- Body Breadth
- 0.056 inch
- Wire Size Max
- 28 AWG
- Wire Size Min
- 30 AWG
