5031751100

Specifications

Number Of Pcb Rows

2

Mating Contact Pitch

0.059 inch

JESD-609 Kodu

e3

Connector Type

Receptacle

Fabrika Tedarik Süresi

44 Weeks

Filter Feature

NO

Sıra Sayısı

1

Number Of Contacts

11

Terminal

Kinked Pin, Solder

Pcb Contact Pattern

STAGGERED

Applications

Automotive, General Purpose, Industrial, Lighting, Medical

Polarization Key

POLARIZED HOUSING

Contact Finish Mating

Tin

Mil Conformance

NO

Çalışma Sıcaklığı

-40°C~105°C

Dielectric Withstanding Voltage

700VAC V

Din Conformance

NO

Yayın Yılı

2010

Seri

CLIK-Mate 503175

Insulation Color

Beige

Reach Svhc

No SVHC

Kurşunsuz Kodu

yes

Body Breadth

0.274 inch

Contact Finish Thickness Mating

39.4μin 1.00μm

Plating Thickness

39μin

Insulation Materials

Polyamide (PA), Nylon

Akım Değeri

2A

Contact Finish Thickness Post

39.4μin 1.00μm

Contact Type

Forked

Reliability

COMMERCIAL

Contact Materials

Copper Alloy

Nem Hassasiyeti (MSL)

1 (Unlimited)

Number Of Positions Loaded

All

Body Depth

0.285 inch

Montaj

Through Hole

Ambalaj

Tray

Mixed Contacts

NO

Glow Wire Compliant

Non-compliant

Pcb Contact Row Spacing

3.7084 mm

Fastening Type

Latch Holder
