Volume pricing
- 1+ pcs$0.45
- 10+ pcs$0.42
- 100+ pcs$0.40
- 500+ pcs$0.38
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Operating Temperature Max
- 85°C
- Contact Termination
- Crimp
- Yayın Yılı
- 2010
- Parça Durumu
- Active
- Dielectric Withstanding Voltage
- 500VAC V
- Pitch
- 0.059 1.50mm
- Kurşunsuz Kodu
- yes
- Polarization Key
- POLARIZED HOUSING
- Filter Feature
- NO
- Insulation Resistance
- 500000000Ohm
- Total Number Of Contacts
- 20
- Din Conformance
- NO
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Mixed Contacts
- NO
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Fabrika Tedarik Süresi
- 14 Weeks
- Mounting Option1
- LOCKING
- Option
- GENERAL PURPOSE
- Additional Feature
- CLIK-MATE, POLARIZED
- Seri
- CLIK-Mate 503149
- RoHS Durumu
- ROHS3 Compliant
- Contact Materials
- NOT SPECIFIED
- Body Depth
- 0.339 inch
- Pozisyon Sayısı
- 20
- Mil Conformance
- NO
- Body Length Or Diameter
- 0.76 inch
- Reliability
- COMMERCIAL
- Ambalaj
- Bulk
- Fastening Type
- Latch Lock
- Sıra Sayısı
- 2
- Note
- Contacts Not Included
- Renk
- Beige
- Contact Type
- Non-Gendered
- Montaj Tipi
- Free Hanging (In-Line)
- Contact Finish Mating
- NOT SPECIFIED
- Connector Type
- Plug
- Iec Conformance
- NO
- Insulation Materials
- POLYBUTYLENE TEREPHTHALATE
- Reference Standard
- UL
- Mounting Option2
- MOUNTING FLANGE
