5025850270

Specifications

Contact Materials

Copper Alloy

Number Of Positions Loaded

All

Insulation Height

0.250 6.35mm

Fabrika Tedarik Süresi

21 Weeks

Ul Flammability Code

94V-0

Seri

CLIK-Mate 502585

Yayın Yılı

2010

Mixed Contacts

NO

Terminal

Solder

Style

Board to Cable/Wire

RoHS Durumu

ROHS3 Compliant

Kurşunsuz Kodu

yes

Filter Feature

NO

Fastening Type

Latch Holder

Contact Finish Mating

Tin

Iec Conformance

NO

Pitch Mating

0.059 1.50mm

Material Flammability Rating

UL94 V-0

Mil Conformance

NO

Connector Type

Receptacle

Applications

Automotive, General Purpose, Industrial, Lighting, Medical

Ambalaj

Tape & Reel (TR)

Din Conformance

NO

Insulation Materials

Resin

Pozisyon Sayısı

2

Parça Durumu

Active

Çalışma Sıcaklığı

-40°C~105°C

Total Number Of Contacts

2

Contact Finish Thickness Mating

39.4μin 1.00μm

Contact Gender

FEMALE

Nem Hassasiyeti (MSL)

1 (Unlimited)

Contact Type

Forked

Özellikler

Pick and Place, Solder Retention

Sıra Sayısı

1

Contact Finish Thickness Post

39.4μin 1.00μm

Insulation Color

Beige

Montaj Tipi

Surface Mount, Right Angle
