5024940270

Specifications

Mil Conformance

NO

Connector Type

Receptacle

Ambalaj

Tape & Reel (TR)

Applications

Automotive, General Purpose, Industrial, Lighting, Medical

Pozisyon Sayısı

2

Insulation Materials

Resin

Din Conformance

NO

Parça Durumu

Active

Çalışma Sıcaklığı

-40°C~105°C

Contact Finish Thickness Mating

39.4μin 1.00μm

Total Number Of Contacts

2

Contact Gender

FEMALE

Nem Hassasiyeti (MSL)

1 (Unlimited)

Özellikler

Pick and Place, Solder Retention

Sıra Sayısı

1

Contact Type

Forked

Insulation Color

Natural

Contact Finish Thickness Post

39.4μin 1.00μm

ECCN Kodu

EAR99

Montaj Tipi

Surface Mount, Right Angle

Contact Materials

Copper Alloy

Number Of Positions Loaded

All

JESD-609 Kodu

e3

Insulation Height

0.270 6.86mm

Fabrika Tedarik Süresi

21 Weeks

Ul Flammability Code

94V-0

Seri

CLIK-Mate 502494

Terminal

Solder

Mixed Contacts

NO

Style

Board to Cable/Wire

RoHS Durumu

ROHS3 Compliant

Filter Feature

NO

Kurşunsuz Kodu

yes

Contact Finish Mating

Tin

Fastening Type

Latch Holder

Pitch Mating

0.079 2.00mm

Iec Conformance

NO

Material Flammability Rating

UL94 V-0
