Specifications
- Özellikler
- Solder Retention
- Insulator Color
- BLACK
- Additional Feature
- SLIMSTACK, LOW PROFILE
- Montaj Tipi
- Surface Mount
- Body Breadth
- 0.081 inch
- Contact Finish Thickness
- 4.00μin 0.100μm
- Plating Thickness
- 8μin
- Contact Gender
- MALE
- Pitch
- 0.016 0.40mm
- Din Conformance
- NO
- Insulation Materials
- GLASS FILLED LIQUID CRYSTAL POLYMER
- Insulation Resistance
- 100000000Ohm
- Rated Current Signal
- 0.3A
- Stack Height Mating
- 1mm
- Operating Temperature Max
- 85°C
- Contact Resistance
- 80mOhm
- Parça Durumu
- Obsolete
- Connector Type
- Plug, Outer Shroud Contacts
- Body Depth
- 0.031 inch
- Contact Style
- BELLOWED TYPE
- Pcb Contact Pattern
- RECTANGULAR
- Kurşunsuz Kodu
- yes
- Mounting Option1
- LOCKING
- Ul Flammability Code
- 94V-0
- Yayın Yılı
- 2015
- Seri
- SlimStack 502430
- Mixed Contacts
- NO
- Board Mounting Option
- FITTING NAIL
- Contact Materials
- PHOSPHOR BRONZE
- Number Of Conductors
- ONE
- JESD-609 Kodu
- e4
- Durability
- 30 Cycles
- Sıra Sayısı
- 2
- Pcb Contact Row Spacing
- 1.7018 mm
- Option
- GENERAL PURPOSE
- Total Number Of Contacts
- 32
- Body Length Or Diameter
- 0.341 inch
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Ambalaj
- Cut Tape (CT)
- Contact Finish
- Gold
