Specifications
- Reliability
- COMMERCIAL
- Number Of Pcb Rows
- 2
- Connector Type
- Receptacle, Center Strip Contacts
- Insulation Resistance
- 100000000Ohm
- Insulation Materials
- GLASS FILLED LIQUID CRYSTAL POLYMER
- Pozisyon Sayısı
- 50
- Pitch
- 0.016 0.40mm
- Height Above Board
- 0.039 1.00mm
- Ambalaj
- Cut Tape (CT)
- Contact Finish
- Gold
- Operating Temperature Max
- 85°C
- Contact Resistance
- 80mOhm
- Parça Durumu
- Active
- Stack Height Mating
- 1mm
- Rated Current Signal
- 0.3A
- Total Number Of Contacts
- 50
- Plating Thickness
- 39μin
- Contact Finish Thickness
- 4.00μin 0.100μm
- Polarization Key
- POLARIZED HOUSING
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Body Length Or Diameter
- 0.516 inch
- Contact Gender
- MALE
- Insulator Color
- BLACK
- HTS Kodu
- 8536.69.40.40
- Özellikler
- Solder Retention
- Sıra Sayısı
- 2
- Montaj Tipi
- Surface Mount
- ECCN Kodu
- EAR99
- Additional Feature
- EMBOSSED TAPE PACKAGING
- Number Of Conductors
- ONE
- Contact Pattern
- RECTANGULAR
- Contact Materials
- PHOSPHOR BRONZE
- Durability
- 30 Cycles
- Fabrika Tedarik Süresi
- 13 Weeks
- Board Mounting Option
- FITTING NAIL
- Seri
- SlimStack 502426
- Yayın Yılı
- 2015
- RoHS Durumu
- ROHS3 Compliant
- Pcb Contact Pattern
- RECTANGULAR
- Mounting Option1
- LOCKING
