Specifications
- Body Depth
- 0.039 inch
- Contact Style
- CENTRONIC
- Pcb Contact Pattern
- RECTANGULAR
- Mounting Option1
- LOCKING
- Kurşunsuz Kodu
- yes
- Ul Flammability Code
- 94V-0
- Board Mounting Option
- FITTING NAIL
- Mixed Contacts
- NO
- Seri
- SlimStack 502426
- Number Of Conductors
- ONE
- JESD-609 Kodu
- e4
- Contact Materials
- PHOSPHOR BRONZE
- Durability
- 30 Cycles
- HTS Kodu
- 8536.69.40.40
- Insulator Color
- BLACK
- Özellikler
- Solder Retention
- Montaj Tipi
- Surface Mount
- Additional Feature
- EMBOSSED TAPE PACKAGING
- Plating Thickness
- 39μin
- Contact Finish Thickness
- 4.00μin 0.100μm
- Polarization Key
- POLARIZED HOUSING
- Contact Gender
- FEMALE
- Insulation Materials
- GLASS FILLED LIQUID CRYSTAL POLYMER
- Din Conformance
- NO
- Insulation Resistance
- 100000000Ohm
- Pitch
- 0.016 0.40mm
- Stack Height Mating
- 1mm
- Parça Durumu
- Active
- Contact Resistance
- 80mOhm
- Operating Temperature Max
- 85°C
- Rated Current Signal
- 0.3A
- Connector Type
- Receptacle, Center Strip Contacts
- Iec Conformance
- NO
- Reference Standard
- UL
- RoHS Durumu
- ROHS3 Compliant
- Operating Temperature Min
- -40°C
- Filter Feature
- NO
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Contact Pattern
- RECTANGULAR
- Fabrika Tedarik Süresi
- 8 Weeks
