Specifications
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Yayın Yılı
- 2015
- Seri
- SlimStack 502426
- Board Mounting Option
- FITTING NAIL
- Mixed Contacts
- NO
- Contact Materials
- NOT SPECIFIED
- Contact Pattern
- RECTANGULAR
- Number Of Conductors
- ONE
- Fabrika Tedarik Süresi
- 13 Weeks
- Durability
- 30 Cycles
- Body Depth
- 0.039 inch
- Iec Conformance
- NO
- Reference Standard
- UL
- Contact Style
- CENTRONIC
- Pcb Contact Pattern
- RECTANGULAR
- RoHS Durumu
- ROHS3 Compliant
- Operating Temperature Min
- -40°C
- Kurşunsuz Kodu
- yes
- Mounting Option1
- LOCKING
- Filter Feature
- NO
- Height Above Board
- 0.039 1.00mm
- Pitch
- 0.016 0.40mm
- Contact Finish
- Gold
- Ambalaj
- Tape & Reel (TR)
- Insulation Materials
- GLASS FILLED LIQUID CRYSTAL POLYMER
- Din Conformance
- NO
- Insulation Resistance
- 100000000Ohm
- Pozisyon Sayısı
- 20
- Rated Current Signal
- 0.3A
- Operating Temperature Max
- 85°C
- Contact Resistance
- 80mOhm
- Parça Durumu
- Active
- Stack Height Mating
- 1mm
- Mil Conformance
- NO
- Reliability
- COMMERCIAL
- Connector Type
- Receptacle, Center Strip Contacts
- Number Of Pcb Rows
- 2
- Insulator Color
- BLACK
- Özellikler
- Solder Retention
- Sıra Sayısı
- 2
