Volume pricing
- 1+ pcs$0.84
- 10+ pcs$0.79
- 100+ pcs$0.75
- 500+ pcs$0.70
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Mounting Option1
- LOCKING
- Contact Resistance
- 20mOhm
- Contact Finish Thickness Post
- 39.4μin 1.00μm
- Kurşunsuz Kodu
- yes
- Total Number Of Contacts
- 12
- Ambalaj
- Tape & Reel (TR)
- Insulation Color
- Natural
- Iec Conformance
- NO
- Din Conformance
- NO
- Montaj Tipi
- Surface Mount
- Seri
- CLIK-Mate 502382
- Terminal
- Solder
- Connector Type
- Receptacle
- Material Flammability Rating
- UL94 V-0
- Yayın Yılı
- 2010
- Style
- Board to Cable/Wire
- Fabrika Tedarik Süresi
- 20 Weeks
- Pcb Contact Pattern
- RECTANGULAR
- Parça Durumu
- Active
- Pitch Mating
- 0.049 1.25mm
- Contact Type
- Forked
- Number Of Positions Loaded
- All
- Sıra Sayısı
- 1
- Additional Feature
- ROHS COMPLIANT, TAPE AND REEL
- Contact Materials
- Copper Alloy
- Current Rating Amps
- 1A
- Insulation Height
- 0.173 4.40mm
- Mating Contact Pitch
- 0.049 inch
- Contact Gender
- FEMALE
- Contact Finish Mating
- Tin
- Çalışma Sıcaklığı
- -40°C~105°C
- Mil Conformance
- NO
- Contact Finish Thickness Mating
- 39.4μin 1.00μm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Özellikler
- Solder Retention
- Filter Feature
- NO
- Fastening Type
- Latch Holder
- Ul Flammability Code
- 94V-0
- JESD-609 Kodu
- e3
- Pozisyon Sayısı
- 12
