Specifications
- Fabrika Tedarik Süresi
- 15 Weeks
- Contact Finish Post
- Tin
- Montaj Tipi
- Surface Mount, Right Angle
- Pitch Mating
- 0.049 1.25mm
- Ambalaj
- Tape & Reel (TR)
- Contact Finish Thickness Mating
- 3.90μin 0.099μm
- Current Rating Amps
- 1A
- Mixed Contacts
- NO
- Connector Type
- Receptacle
- Kurşunsuz Kodu
- yes
- Yayın Yılı
- 2012
- Contact Gender
- FEMALE
- Özellikler
- Pick and Place, Solder Retention
- Insulation Materials
- Polyamide (PA), Nylon
- Applications
- General Purpose
- Style
- Board to Cable/Wire
- Nominal Gerilim
- 50V
- Contact Finish Mating
- Gold
- Contact Finish Thickness Post
- 39.4μin 1.00μm
- Mil Conformance
- NO
- Seri
- Duo-Clasp 502046
- Contact Materials
- Copper Alloy
- Parça Durumu
- Active
- Insulation Height
- 0.295 7.50mm
- Sıra Sayısı
- 2
- Terminal
- Solder
- RoHS Durumu
- ROHS3 Compliant
- Total Number Of Contacts
- 30
- Material Flammability Rating
- UL94 V-0
- Filter Feature
- NO
- Din Conformance
- NO
- Pozisyon Sayısı
- 30
- JESD-609 Kodu
- e3
- Fastening Type
- Detent Lock
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Insulation Color
- Natural
- Contact Type
- Forked
- Number Of Positions Loaded
- All
- Çalışma Sıcaklığı
- -25°C~85°C
- Iec Conformance
- NO
