Specifications
- Style
- Board to Cable/Wire
- Contact Shape
- Square
- Pitch Mating
- 0.039 1.00mm
- Contact Type
- Male Pin
- Number Of Positions Loaded
- All
- Connector Type
- Header
- Pozisyon Sayısı
- 4
- Insulation Color
- Natural
- ECCN Kodu
- EAR99
- Fabrika Tedarik Süresi
- 12 Weeks
- Kurşunsuz Kodu
- yes
- Material Flammability Rating
- UL94 V-0
- Ambalaj
- Tape & Reel (TR)
- Parça Durumu
- Active
- Montaj Tipi
- Surface Mount
- Terminal
- Solder
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Materials
- Phosphor Bronze
- Stack Height Mating
- 7.3mm
- Yayın Yılı
- 2007
- Insulation Height
- 0.213 5.40mm
- Seri
- Pico-Clasp 501940
- Özellikler
- Pick and Place, Solder Retention
- Applications
- General Purpose
- Contact Finish Mating
- Tin
- Contact Finish Thickness Mating
- 39.4μin 1.00μm
- RoHS Durumu
- ROHS3 Compliant
- Insulation Materials
- Polyamide (PA), Nylon
- Fastening Type
- Locking Ramp
- Shrouding
- Shrouded - 4 Wall
- Sıra Sayısı
- 1
