5016453420

Specifications

Montaj Tipi

Through Hole

Style

Board to Cable/Wire

Pitch Mating

0.079 2.00mm

Sıra Sayısı

2

Shrouding

Shrouded - 4 Wall

Insulation Color

Natural

Insulation Height

0.472 12.00mm

RoHS Durumu

ROHS3 Compliant

Connector Type

Header

Terminal

Solder

Row Spacing Mating

0.079 (2.00mm)

Contact Finish Mating

Tin

Contact Type

Male Pin

Ambalaj

Tray

Fabrika Tedarik Süresi

6 Weeks

Material Flammability Rating

UL94 V-0

Nem Hassasiyeti (MSL)

1 (Unlimited)

Seri

iGrid 501645

Applications

Automotive, General Purpose, Industrial, Medical, Telecommunications

Contact Materials

Brass

Pozisyon Sayısı

34

Insulation Materials

Polyamide (PA66), Nylon 6/6, Glass Filled

Number Of Positions Loaded

All

Özellikler

Board Guide

Fastening Type

Latch Holder

Kurşunsuz Kodu

yes

Contact Shape

Square

Contact Length Post

0.126 3.20mm

Parça Durumu

Active
