5016452220

Specifications

Kurşunsuz Kodu

yes

Fastening Type

Latch Holder

Yayın Yılı

2005

Parça Durumu

Active

Contact Length Post

0.126 3.20mm

Contact Shape

Square

Pozisyon Sayısı

22

Insulation Materials

Polyamide (PA66), Nylon 6/6, Glass Filled

Contact Materials

Brass

Applications

Automotive, General Purpose, Industrial, Medical, Telecommunications

Özellikler

Board Guide

Number Of Positions Loaded

All

Contact Type

Male Pin

Contact Finish Mating

Tin

Row Spacing Mating

0.079 (2.00mm)

Seri

iGrid 501645

Ambalaj

Tray

Nem Hassasiyeti (MSL)

1 (Unlimited)

Material Flammability Rating

UL94 V-0

Fabrika Tedarik Süresi

7 Weeks

Shrouding

Shrouded - 4 Wall

Sıra Sayısı

2

Insulation Color

Natural

Montaj Tipi

Through Hole

REACH Uyumluluk Kodu

unknown

Pitch Mating

0.079 2.00mm

Style

Board to Cable/Wire

Terminal

Solder

Connector Type

Header

RoHS Durumu

ROHS3 Compliant

Insulation Height

0.472 12.00mm
