Specifications
- Pitch
- 0.016 0.40mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Maks. Çalışma Sıcaklığı
- 85°C
- Ul Flammability Code
- 94V-0
- Seri
- SlimStack 501594
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Iec Conformance
- NO
- Option
- GENERAL PURPOSE
- Rated Current Signal
- 0.3A
- Contact Resistance
- 90mOhm
- Dielectric Withstanding Voltage
- 176VAC V
- Orientation
- Vertical
- Insulation Resistance
- 100000000Ohm
- Min. Çalışma Sıcaklığı
- -25°C
- Height Above Board
- 0.028 0.71mm
- Parça Durumu
- Active
- Mil Conformance
- NO
- Contact Finish
- Gold
- Yayın Yılı
- 2015
- Pcb Contact Pattern
- RECTANGULAR
- Kurşunsuz Kodu
- yes
- Din Conformance
- NO
- Özellikler
- Solder Retention
- Stack Height
- 900μm
- Contact Pattern
- RECTANGULAR
- Contact Materials
- Bronze
- Contact Gender
- MALE
- Fabrika Tedarik Süresi
- 18 Weeks
- Contact Finish Thickness
- 3.94μin 0.10μm
- Ambalaj
- Cut Tape (CT)
- Housing Material
- Thermoplastic
- Montaj
- Surface Mount
- Body Breadth
- 0.078 inch
- RoHS Durumu
- ROHS3 Compliant
- Terminal
- SMD/SMT
- Number Of Pcb Rows
- 2
- Connector Type
- Plug, Outer Shroud Contacts
- Polarization Key
- POLARIZED HOUSING
- Reliability
- COMMERCIAL
- Insulator Color
- BLACK
