Specifications
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Total Number Of Contacts
- 70
- Ul Flammability Code
- 94V-0
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Pitch
- 0.016 0.40mm
- Seri
- SlimStack 501591
- Insulation Resistance
- 100000000Ohm
- Rated Current Signal
- 0.3A
- Iec Conformance
- NO
- Board Mounting Option
- FITTING NAIL
- Option
- GENERAL PURPOSE
- Dielectric Withstanding Voltage
- 176VAC V
- Contact Resistance
- 90mOhm
- Body Depth
- 0.035 inch
- Contact Finish
- Gold
- Yayın Yılı
- 2010
- Din Conformance
- NO
- Kurşunsuz Kodu
- yes
- Pcb Contact Pattern
- RECTANGULAR
- Operating Temperature Max
- 85°C
- Height Above Board
- 0.035 0.88mm
- Mil Conformance
- NO
- Parça Durumu
- Active
- Contact Materials
- PHOSPHOR BRONZE
- Contact Pattern
- RECTANGULAR
- Contact Gender
- FEMALE
- Body Length Or Diameter
- 0.673 inch
- Özellikler
- Solder Retention
- Body Breadth
- 0.134 inch
- Ambalaj
- Tape & Reel (TR)
- Contact Finish Thickness
- 3.94μin 0.10μm
- Fabrika Tedarik Süresi
- 17 Weeks
- HTS Kodu
- 8536.69.40.40
- Montaj Tipi
- Surface Mount
- Reference Standard
- UL
- Stack Height Mating
- 0.9mm
- Sıra Sayısı
- 2
- Number Of Conductors
- ONE
- RoHS Durumu
- ROHS3 Compliant
- Insulator Color
- BLACK
