Specifications
- Contact Finish Mating
- Tin
- Max Voltage Rating Ac
- 50V
- Contact Type
- Male Pin
- Montaj
- Surface Mount
- Housing Material
- Thermoplastic
- Radyasyon Dayanımı
- No
- Uzunluk
- 17mm
- Seri
- Pico-Clasp 501568
- Fabrika Tedarik Süresi
- 13 Weeks
- Material Flammability Rating
- UL94 V-0
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Maks. Çalışma Sıcaklığı
- 85°C
- Ambalaj
- Tape & Reel (TR)
- Reach Svhc
- No SVHC
- Contact Finish Thickness Mating
- 40.0μin 1.02μm
- Sıra Sayısı
- 1
- Shrouding
- Shrouded - 4 Wall
- Min. Çalışma Sıcaklığı
- -40°C
- Style
- Board to Cable/Wire
- Pitch Mating
- 0.039 1.00mm
- Lead Pitch
- 1mm
- Orientation
- Right Angle
- Montaj Tipi
- Surface Mount, Right Angle
- Akım Değeri
- 1A
- Connector Type
- Header
- Terminal
- Solder
- RoHS Durumu
- ROHS3 Compliant
- Insulation Height
- 0.185 4.70mm
- Max Voltage Rating Dc
- 50V
- Fastening Type
- Latch Holder
- Yayın Yılı
- 2016
- Parça Durumu
- Active
- Glow Wire Compliant
- Non-compliant
- Number Of Contacts
- 15
- Contact Shape
- Square
- Insulation Materials
- Polyamide (PA), Nylon
- Housing Color
- Natural
- Kurşunsuz
- Lead Free
- Depth
- 5.35mm
- Contact Materials
- Phosphor Bronze
