Specifications
- Seri
- Pico-Clasp 501568
- Contact Finish Thickness Mating
- 40.0μin 1.02μm
- Reach Svhc
- No SVHC
- Maks. Çalışma Sıcaklığı
- 85°C
- Pitch
- 1mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Material Flammability Rating
- UL94 V-0
- Contact Type
- Male Pin
- Max Voltage Rating Ac
- 50V
- Min. Çalışma Sıcaklığı
- -40°C
- Shrouding
- Shrouded - 4 Wall
- Orientation
- Right Angle
- Lead Pitch
- 1mm
- Style
- Board to Cable/Wire
- Parça Durumu
- Active
- Nominal Gerilim
- 50V
- Yayın Yılı
- 2007
- Fastening Type
- Latch Holder
- Max Voltage Rating Dc
- 5.05kV
- Özellikler
- Solder Retention
- Number Of Circuits
- 12
- Contact Gender
- Male
- Contact Materials
- Phosphor Bronze
- Depth
- 5.35mm
- Uzunluk
- 14mm
- Radyasyon Dayanımı
- No
- Housing Material
- Thermoplastic
- Ambalaj
- Cut Tape (CT)
- Fabrika Tedarik Süresi
- 13 Weeks
- Contact Finish Mating
- Tin
- Voltage Rated Dc
- 50V
- Montaj
- Surface Mount
- Contact Finish Post
- Tin
- Terminal
- Solder
- Connector Type
- Header
- Insulation Height
- 0.185 4.70mm
- RoHS Durumu
- ROHS3 Compliant
- Renk
- Natural
- Contact Plating
- Tin
- Sıra Sayısı
- 1
